Submarsible Flat Cable

Submarsible Flat Cable Specification

Cable Length
100 Meter Roll or as Required

Conductor Type
Multistrand/Annealed

Temperature
-10C to +70C

Connector Type
Stripped Ends

No Of Core
2 Core / 3 Core

Product Type
Submersible Flat Cable

Material
PVC, Copper

Function
Power Transmission to Submersible Pumps

Usage
Suitable for submersible pumps in deep wells

Voltage Surge
Up to 2.5 kV

Frequency (MHz)
50/60 Hz

Rated Voltage
1100 V

Rated Current
As per IS:694 Standards

Cable Capacity
Varies by Size (16A to 54A)

Insulation Material
PVC

Conductor Material
Copper

Length
100 Meter (Standard Roll)

Size
1.0 Sq.mm to 16 Sq.mm

Color
Black, Blue, Yellow, Red

Diameter
As per Size Specifications

Application
Submersible Pumps, Agricultural, Irrigation

Flame Retardant
Yes

Short Circuit Rating
160C (Max)

Flexibility
High, suitable for continuous immersion

Insulation Resistance
> 36 mega ohm/km at 27C

Standard
ISI Marked, IS:694

Test Voltage
3.0 kV (AC)

Bending Radius
As per manufacturer standards

Sheath Type
PVC Flat Sheath

Submarsible Flat Cable Trade Information

Minimum Order Quantity
50 Pieces

Delivery Time
5-7 Days

About Submarsible Flat Cable

The Submersible Flat Cable-boasting popular acclaim among agricultural and industrial sectors-takes the spotlight for its eminent performance in power transmission to deep-well submersible pumps. Engineered with a sublime PVC flat sheath, this cable flaunts flame-retardant properties, exceptional insulation resistance (>36 mega ohm/km at 27C), and a perfect test voltage endurance of 3.0 kV AC. ISI Marked and highly flexible, each cable delivers reliable operation, even under continuous immersion. Redeem peace of mind with its robust copper core and versatile color selection. An eminent choice for flawless installation and long-term dependability.

Applications and User Profile

The Submersible Flat Cable is meticulously designed for flawless application in submersible pumps, both in deep wells and open water bodies. Its ideal usage spans agricultural irrigation, industrial water systems, and domestic supply. Farmers, pump operators, and maintenance technicians particularly benefit from its sublime flexibility and perfect insulation. Installation is straightforward-simply connect the stripped ends to the pump terminal and power supply, ensuring dependable performance even in challenging environments.

Supply Ability and Packaging

This cable is shipped nationwide with robust packaging-each standard roll is 100 meters, with additional custom lengths available on request. Reliable transport services ensure swift deliveries across the main domestic market, offering a cost-effective outlay for bulk buyers. The packaging is secure, protecting the eminent cable during transit and guaranteeing that it arrives pristine. From factory floor to field, every shipment is handled with care, so clients can redeem optimum satisfaction.

FAQ's of Submarsible Flat Cable:

Q: How do I properly install the Submersible Flat Cable in a pump system?

A: Begin by securely connecting the stripped cable ends to the pump terminals and power source, following manufacturer guidelines for bending radius and ensuring watertight sealing for submerged applications.

Q: What applications are best suited for the Submersible Flat Cable?

A: This cable is tailored for submersible pumps operating in deep wells, agricultural irrigation systems, industrial water setups, and residential water supply, excelling in environments requiring continuous immersion and reliability.

Q: When should I replace my submersible flat cable?

A: It is recommended to inspect cables during routine maintenance and replace them immediately if there are signs of insulation wear, reduced flexibility, or electrical faults to maintain optimum operation and safety.

Q: Where are the main domestic markets served by this cable?

A: The Submersible Flat Cable is shipped to various domestic markets across the country, including rural, agricultural, and industrial zones that require reliable water management solutions.

Q: What is the process for redeeming warranty or support for the cable?

A: Warranty or support can be redeemed by contacting the supplier or manufacturer with the purchase documentation and details of the issue; they will guide you through the process for effective resolution.

Q: What are the benefits of using a flame-retardant, ISI marked cable for submersible pumps?

A: Benefits include enhanced safety due to flame retardant qualities, compliance with stringent IS:694 standards, superior flexibility, high insulation, and reliable performance in submerged and demanding conditions.
